  1. How to test and check Mic issue for JOYING Android head unit?

    How to test and check Mic issue for JOYING Android head unit?

    When received Joying Android head unit, some customer will feedback that there is some problem of the mic, for example:
    1) When make Bluetooth phone calls, why i can hear my friend's voice, but my friend can not hear my voice, just silence?
    2) When make Bluetooth phone calls, why i can not hear my friend's voice, but my friend can hear my voice?

    After testing and checking, finally found out that usually this is not the problem of JOYING head unit, also not the problem of the microphone, but other problem which is not related with the head unit.

    So if you also meet such issue when use Joying Android head unit first time, do not worry, i hope you can follow below solution to have a check and test first, if still have problem, you can contact us by europe@joyingauto.com

    First case: When make Bluetooth phone calls, i can hear my friend's voice, but my friend can not hear my voice.

    Example 1:

    Herbert said "I wan to ask about the head unit.. it works very good everything is working except when i try call someone using bluetooth i can hear them but they cant hear me, is there a setting that i can change so they can hear me?"





    After several time testing and checking, Herbert has solved this issue, because he find that he extend the usb and the mic socket. when remove the extension then it works fine



    This is the picture of the usb and mic socket, pls do not use it.



    Example 2:

    Thiago said "Hi guys! I've bought a CRV head unit, received the rear camera and the multimedia stuff, everything is fine. Just a bit of a problem: the mic (for the bluetooth calls) doesn't work, neither the external nor the internal. I've taken the SUV to a seasoned professional, who did all the wiring and setups and everything. My only issue is realy the mic, we couldn't get it to work. I'm able to take incoming calls and I listen very fine the person whom I'm talking to, but he/she doesn't hear a single noise from me."



    After several time testing and checking, Thiago has solved this issue, he found that there is some mistake on his mobile phone's configuration, as it can work good with other mobile phone, so hope you can try other mobile phone.





    Example 3:
    Ben said "i bout Joying 10.1 inch 6.1 android.its work good but i got problem whit the mic.when i call someone i can hear them but he cant hear me.i try to sovle it but nothnig work."





    For this customer we have tried many times to do testing and checking, but none solution works, finally our engineer said hope he can open the head unit and show the mic antenna to us, he send the picture, we have a check, but still do not find out any problem, while Ben send an email to me that the mic works now, do not know why, but it works, we guess that he may unplug and plug the external mic:

    When you want use external mic, pls make sure that you have connected the external mic well:



    Second case: When make Bluetooth phone calls, i can not hear my friend's voice, but my friend can hear my voice.

    Example 1:

    Joe said: "So after buying a head unit for my explorer I fell in love with your product. They are so nice. I ended up getting another one for a different vehicle last week from amazon. Everything works great but the back up camera and the bluetooth when connected to my phone. The backup camera is not clear, the picture is distorted I thought it was interference from a power wire so I moved it and it still looks the same. The bluetooth audio works great but when Im making a call I cannot hear anything unless its turned all the way up. Then I can barely hear it and it is really scratchy. I turned up the bluetooth audio in the setting menu but it didnt change anything. is there anything else I can do or do I have a bad unit. It works perfect in the first head unit i bought. The one I just got was the JY-UMS02"



    I ask Joe to check the speaker wire, to see if he connect the front speaker and rear speaker wire wrong.
    Because when make Bluetooth phone calls, only front speaker have sound, rear speaker won't have sound, so if he connect front speaker and rear speaker wire wrong, then Joe won't hear any sound from his friends. After tried to check this, Joe said he indeed connect wrong speaker wire, finally solve this issue.

    So if you have the same issue, pls do not worry, you can test and check first according to above solution, if the problem still, you can contact us freely.

    Joying official website: https://www.joyingauto.com/
    Joying europe website: https://www.joyingauto.eu/
    Joying Youtube: https://www.youtube.com/c/BoykaJoying
    Facebook: https://www.facebook.com/joyingandroidstereo/
    Twitter: https://twitter.com/joyingauto

    Continus Reading »
  2. How To Learn And Set The Left Touch Screen Button Function ?

    How To Learn And Set The Left Touch Screen Button Function ?



    Sometimes when touch screen can not work or can not work properly when you receive the head unit, pls do not worry, that is not quality problems, just do as below, then this issue can be solved :-)

    Customer's problem:

    Thanks for getting back to me, I did get everything working...

    But I am having an issue, the buttons on the left are not responsive. The power, home, volume, gps and back buttons. I have to tap them like 10 times to work once. I bought the device off of amazon just a few days ago.

    Let me know what I can do or try.

    Thanks Mike



    JOYING Reply:

    Pls relearn the panel keys study as following steps:

    First you need push "Clear" first, next need push for example the power button on the screen and then push power button on the left side, the same as other button like home, volume+/- etc
    Last push the save button on the screen, for the details, pls check as below:


    Here is a video for your ref:

    Detailed description with pictures:

    First find touch screen study in car settings (password is 3368 or 126 or 0000 )



    Second pls click "ClEAR" first as below and then re-learning all the buttons

    At last, after re-learning, you need click "SAVE" button, then will be ok:

    After try to do like this, Mike said "Thanks so much that worked :)"

    Joying official website: https://www.joyingauto.com/
    Joying europe website: https://www.joyingauto.eu/
    Joying Youtube: https://www.youtube.com/c/BoykaJoying
    Facebook: https://www.facebook.com/joyingandroidstereo/
    Twitter: https://twitter.com/joyingauto





    Continus Reading »
  3. Joying Android 6.0 8 Inch 9 Inch Car GPS Navi Multimedia System for Toyota

    新建网页 2

    Joying Android 6.0 8 Inch 9 Inch Car GPS Navi Multimedia System for Toyota

      What we can offer?

    * Android 6.0, Quad core, 2GB ram, 32GB flash

    * Includes suitable toyota universal harness, support steering wheel control and
    * Support sub control, Built in wifi, Bluetooth 4.0, pre-install GPS map

    Note: If your Toyota car have JBL system, also can install our head unit, but need purchase extra JBL harness from other place(Before purchase pls confirm if that JBL harness can fit with your car or not


    Applicable Car & Year: Toyota Camry Aurion 2006-2011

    8 Inch Toyota Camry Aurion Head Unit

    Customers' Review:
    Stereo looks nice and like factory fit for 2009 camry hybrid with jbl. Starts up instantly on car start. Jbl system works perfectly with Metra JBL amplifier. The play store allows to install new apps and home launcher. Octa core processor would be best, though speed is good enough.
    I can only try to describe how much I love this thing! Buy it! It is high quality and very easy to install. Sounds way better than my factory unit. The unit is super fast and responsive. Steering wheel controls work perfectly, lights match other interior, lights, near perfect factory finish, and spot on fit. Joying is also responsive with any needs.

    Review video & Installation video:

    Toyota Camry 2009

    9 Inch Toyota Camry Aurion Head Unit

    Customers' Review:
    Wish I could give it 6 stars. 100% plug in play in a 2010 Camry. I did encounter a few very minor fitment problems that were easily overcome. If you have the ability to install a head unit, this unit is a piece of cake. Works,sounds and looks great, actually looks oem. GPS has the best sensitivity and quick response time of any I've every used. I have nothing negative to say about this unit - that a big statement coming form me!
    So far so great. I'd been in the market for an upgrade for sometime but was waiting for something new and classy, this unit hits the mark.
    Initially I wasn't expecting much for the price but upon installation have zero complaints and have already gained many compliments. The screen is crisp and clear, the buttons are extremely responsive, and the capability is unlimited. Steering wheel controls are fully functional, Wi-Fi, Bluetooth, you name it.

    I have 2011 camry.. it fix on my car.. i really loved it i don't have to say anything

    Review video for your ref:

    8 " Toyota universal head unit

    Applicable Car & Year:



    8 inch Toyota universal unit installed on 2007 Toytoa 4runner SR5

    8 inch Toyota universal unit installed on 07 Toyota FJ Cruiser

    Here is the video on how you remove the old CD player and install our head unit on your toyota car .



    If you are also interested in our Android head unit for your Toyota Car, you can purchase directly from our official website, also can contact us firstly by email europe@joyingauto.com





    Continus Reading »
  4. Joying head unit installed in Jeep/Dodge/Chrysler car

    Joying head unit installed in Jeep/Dodge/Chrysler car


    Jeep/Dodge/Chrysler car brand is very popular and common in USA market, here want to introduce which Android head unit/car stereo is available in JOYING for Jeep/Dodge/Chrysler car including big screen Android car stereo



    For Jeep/Dodge/Chrysler car year and dashboard like below:

    Chrysler 300 2008-2010 Dodge Dakota 2008-2011
    Chrysler 200 2011+ Dodge Durango 2008-2009
    Chrysler Aspen 2008-2009 Dodge Nitro 2006-2011
    Chrysler Sebring 2007-2010 Dodge Ram 2009-2012
    Chrysler Sebring 2007-2010 Jeep Commander 2008-2010
    Chrysler Town&Country 2008+ Jeep Compass 2009+
    Chrysler Caravan 2008+ Jeep Grand Cherokee 2008-2010
    Dodge Avenger 2007+ Jeep Liberty 2008+
    Dodge Caliber 2009-2012 Jeep Patriot 2009+
    Dodge Challenger 2008+ Jeep Wrangler 2007+
    Dodge Charger 2008-2010

    Jeep Grand Cherokee

    2008 Jeep Grand Cherokee

    There are two options for you to install Joying head unit:

    Option one: Joying 6.2 inch Jeep head unit specially design for Jeep/Dodge/Chrysler car, plug and play.

    Joying Jeep Android Head Unit

    10.1 inch single din installed in Dodge Grand Caravan 2015



    Following is the feedback video :



    For Jeep/Dodge/Chrysler car year and dashboard like below:

    Chrysler 300C 2005-2007 Dodge Durango 2004-2007
    Chrysler PT Cruiser 2006-2010 Jeep Grand Cherokee 2005-2007
    Dodge Charger 2006-2007 Jeep Commander 2006-2007
    Dodge Ram 2006-2008 Jeep Compass 2007-2008
    Dodge Dakota 2005-2007 Dodge Magnum 2005-2007

    2007 Chrysler Aspen



    You can install Joying 7 inch 8 inch 10.1 inch head unit, but need purchase suitable single din dash kit and suitable canbus harness as PAC brand from other place, you can search online or contact us via email europe@joyingauto.com

    Review picture after installation:

    7 inch single din installed on 2005 Chrysler 300C

    8 inch single din installed on Dodge Grand Caravan 2015



    For Jeep/Dodge/Chrysler car year and dashboard like below:

    Chrysler 300M 1999-2004 Dodge Caravan 2001-2007
    Chrysler Concorde 1998-2004 Dodge Dacota 2001-2004
    Chrysler LHS 1998-2001 Dodge Stratus 2001-2004
    Chrysler PT Cruiser 2000-2005 Dodge Durango 2001-2003
    Chrysler Sebring 2001-2006 Dodge Neon 2000-2006
    Chrysler Town&Country 2001-2007 Dodge Ram 2000-2005
    Jeep Grand Cherokee 1999-2004 Dodge Status 2001-2006
    Jeep Liberty 2002-2007 Dodge Van 2002-2003
    Jeep Wrangler 2003-2006 Dodge Viper 2003-2009



    2004 Dodge Dakota

    2005 Chrysler PT Cruiser

    2001 Jeep Grand Cherokee

    Joying single din head unit installation video:



    For Jeep/Dodge/Chrysler car year and dashboard like below:

    Chrysler Sebring 1995-2000 Dodge Aries 1984-1989
    Chrysler Concorde 1993-1997 Dodge Caravan 1984-2000
    Chrysler Cordoba 1979-1983 Dodge Dakota 1987-2000
    Chrysler E-Class 1983-1984 Dodge Durango 1998-2000
    Chrysler Laser 1984-1986 Dodge Dynasty 1988-1993
    Chrysler Imperian 1979-1993 Dodge Lancer 1985-1989
    Chrysler Le Baron 1977-1995 Dodge Neon 1995-1999
    Chrysler LHS 1994-1997 Dodge Ram 1984-2001
    Chrysler Newport 1975-1981 Dodge Shadow 1987-1994
    Chrysler Town&Country 1990-2000 Dodge Van 1978 2001
    Jeep Cherokee 1997-2001 Jeep Grand Cherokee 1996-1998
    Jeep Vision 1993-1997 Jeep Wrangler 1997-2002

     2001 Jeep Cherokee

    Also can install Joying 7 inch 8 inch 10.1 inch single din head unit, but need purchase suitable single din dash kit and suitable harness from other place, you can search on internet or contact us via email europe@joyingauto.com

    Review picture after installation:

    10.1 inch head unit installed on 2001 Jeep Cherokee



    Note: Joying single din universal head unit includes the standard ISO harness, if you need other canbus harness to decode your factory amplifier, need purchase from other place, also can contact us for some suggestions

    If you are interested this Android head unit for your Jeep/Dodge/Chrysler car, you can purchase directly from our official website, also can contact us first by email europe@joyingauto.com



    Joying official website: https://www.joyingauto.com/
    Joying europe: https://www.joyingauto.eu/
    Joying Youtube: https://www.youtube.com/c/BoykaJoying
    Facebook: https://www.facebook.com/joyingandroidstereo/
    Twitter: https://twitter.com/joyingauto

    Continus Reading »
  5. JOYING 2GB RAM 32GB ROM Octa Core CPU Android 6.0 Car Stereo Latest Update

    新建网页 2

    JOYING 2GB RAM 32GB ROM Octa Core CPU Android 6.0 Car Stereo Latest Update



    Note: this update is only workable for Android 6.0 car radio with octa core CPU with 2GB RAM+32GB ROM . Please contact us if you are not clear your head unit system .
     otherwise the head unit will be damaged .







    Following is the updated files (2018-5-11 ) for Octa Core Processor Android Car Radio with 2GB RAM + 32GB ROM


    please noted : This firmware is only available for Joying FYT Android 6.0.1 PX5 Octa Core 2GB+32GB Radio. Pls attention: This firmware is NOT fit for Android 8.0 octa core radios, Not for 8 inch VW head unit with DVD player(JY-VM130P2), also Not for screen resolution 800*480 models. This firmware is mainly for the head unit bought before March 2018.


    Update Guideline:
    Here is the firmware for 1024*600 resolution models . please click Here
    Applicable Car Models: JY-UM135P2, JY-UM128P2, JY-UM138P2, JY-UM134P2, JY-UMS01P2, JY-UMS02P2, JY-UMS03P2, JY-VM131P2, JY-TM138P2, JY-NM135P2, JY-NM138P2, JY-NM134P2, JY-HM135P2, JY-HYM135P2

    Here is the firmware for 1280*480 resolution models. please click Here
    Applicable Car Models: JY-HCS01P2(8.8 inch), JY-HCS02P2(10.25 inch)

    Following is the video on how to update :


    1). Pls download the firmware from your windows system computer and unzip it.
    2). Copy the unzipped files into an empty USB FAT32 or empty C10 32GB SD card.
    3). Insert the USB into car radio USB port or SD card into unit GPS map slot, then the unit will update automatically.
    4). During the update, please do not operate it and just wait it until the screen remind you to move SD card or USB.
    5). The item will reboot automatically.

    After you update the head unit, please note that below things.
    1) Touch calibration again.
    2) Remap touch button on the left side of front panel if your car stereo is full touch screen model.
    3) Set canbus protocol again like the one as before update if your android car radio is BMW, W, Audi or Opel.
    4) If your android car radio is without digital amplifier, please choose No amp; If your android car radio is with digital amplifier, please choose AMP (in).

    News for this update:
    1). Optimized the Bluetooth (Bluetooth connecting and bluetooth music sound issue)
    2). Optimized the OBD
    3). Optimized the music sound issue via Apple CarPlay function
    4). Optimized the unit screen display color saturability
    5). Optimized the system, make the operation smoother


    Following is the updated files (2018-1-26 ) for Octa Core Processor Android Car Radio with 2GB RAM + 32GB ROM


    Here is system update link for HD 1024*600 resolution , please click Here .


    Here is the video on how to update the system :

    Before you update the head unit, please backup all important things:
    1) Copy maps from car stereo internal storage to SD card.
    2) Go to settings-factory- enter password 3368- car model to check canbus protocol and record it.
    3) Use a good quality SD card or USB to update it (format the SD card or USB as FAT32)



    After you finish the update, you are required to do the below things:
    1) Remap touch button on the front panel.
    2) Touch calibration.
    3) Enter the Car Settings application- go to the lower right tab (the one with the screwdriver) click on it and enter 3368- go to the AMP Enable option and turn it off-Go to the EQ menu (second lower tab from right to left) of the car settings and now have the keyboard pitch option. Note: If your android car radio is with digital amplifier, please choose AMP (in).
    4) Go to radio settings, turn on two option: auto sens and RDS. If you hear background noise after searching radio station, please turn off stereo option.
    5) If your android car radio is BMW, VW, Audi or Opel, you need to set canbus protocol again like the one as before update.




    Note:
    1) Fix OBD connection problem, the code of paring OBD is 1234.
    2) After you update, you need to connect WiFi to activate carplay function. Only left side USB port has carplay function. if you want to use Android auto, please insatll android auto app from google play store, then connect android Phone via USB cable to left side USB port. Connect Bluetooth, and android auto function can work.
    3) Optimize widgets usage.
    4) Fix popping problem when you exit single app use.
    5)If your car stereo is VW special model, front and parking sensor can work well after this update.

    Have any problems during update , please contact us europe@joyingauto.com. we will try best to help you .





    Continus Reading »
  6. JOYING Octa Core Processor Android Car Radio Latest Update with 2GB /4GB RAM + 16GB ROM /32GB

    JOYING Octa Core Processor Android 8.0 Car Radio Latest Update with 2GB /4GBRAM + 16GB ROM /32GB




    Note: this update is only workable for Android car radio with octa core CPU with 2GB RAM+16GB ROM . Please contact us if you are not clear your head unit system .
     otherwise the head unit will be damaged .


    Following is the updated files for Octa Core Processor Android 8.0 Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM /64GB
    please noted : it can solve the android auto function supported by android 8.0 phone .
    Android 8.0 update to Android 8.1 or Android 8.1 update to Android 8.1

    Before update , you need to clarify your head unit with or without DSP (motherboard comes with nut chips )
    following will be shown on pictures and help you how to distinguish. (if you still not clear , please contact us europe@joyingauto.com )

    Following updated files for resolution 1024*600 models ,
    MCU file please click Here
    OS file please click Here

    Available unit :
    JY-UO135N2PXC,JY-UO135N2PX5R,JY-UO135N2PX5,JY-UOS04N2PX5, JY-UOS01N4PX5, JY-UOS03N4PX5,JY-UOS02N4PX5
    JY-UOS03N4PX5S, JY-UO135N4PX5,JY-UO138N4PX5,JY-UO134N4PX5,JY-UO135N4PX5S,JY-UO138N4PX5S
    JY-KO002N4PX5S,JY-KO003N4PX5S,JY-HO122N4PX5S,JY-FO127N4PX5S,JY-FO128N4PX5S,JY-TO151N4PX5S,JY-TO152N4PX5S,JY-TO153N4PX5S,
    JY-TO154N4PX5S,JY-TO155N4PX5S,JY-TO156N4PX5S,JY-TO157N4PX5S,JY-TO158N4PX5S,JY-TO159N4PX5S, JY-HO140N4PX5S,JY-HO141N4PX5S,JY-HO142N4PX5S
    JY-HO143N4PX5S,JY-VO134N4PX5S,JY-HO001N4PX5S,JY-HO002N4PX5S,JY-HO003N4PX5S,JY-NO001N4PX5S,JY-PO148N4PX5S,JY-PO138N4PX5S


    Following updated files for resolution 1024*600 models with DSP (motherboard comes with nut chips )
    MCU file please click Here
    OS file please click Here

    Available unit :
    JY-UO135N2PXC,JY-UO135N2PX5R,JY-UO135N2PX5,, JY-UOS03N4PX5,JY-UOS02N4PX5
    JY-UOS03N4PX5S, JY-UO135N4PX5,JY-UO138N4PX5,JY-UO134N4PX5,JY-UO135N4PX5S,JY-UO138N4PX5S
    JY-KO002N4PX5S,JY-KO003N4PX5S,JY-HO122N4PX5S,JY-FO127N4PX5S,JY-FO128N4PX5S,JY-TO151N4PX5S,JY-TO152N4PX5S,JY-TO153N4PX5S,
    JY-TO154N4PX5S,JY-TO155N4PX5S,JY-TO156N4PX5S,JY-TO157N4PX5S,JY-TO158N4PX5S,JY-TO159N4PX5S, JY-HO140N4PX5S,JY-HO141N4PX5S,JY-HO142N4PX5S
    JY-HO143N4PX5S,JY-VO134N4PX5S,JY-HO001N4PX5S,JY-HO002N4PX5S,JY-HO003N4PX5S,JY-NO001N4PX5S,JY-PO148N4PX5S,JY-PO138N4PX5S





    Following updated files for resolution 800*480 models
    MCU file please click Here
    OS file please click Here

    Available unit : JY-JO001N4PX5S


    Following updated files for resolution 800*480 models with DSP (motherboard comes with nut chips )
    MCU file please click Here
    OS file please click Here

    Available unit : JY-JO001N4PX5S



    Following updated files for 9.7 inch horizontal models
    MCU file please click Here
    OS file please click Here

    Available unit :  JY-VOS06N4PX5S,JY-UO136N4PX5S



    Following updated files for 9.7 inch horizontal models with DSP (motherboard comes with nut chips )
    MCU file please click Here
    OS file please click Here

    Available unit :  JY-VOS06N4PX5S,JY-UO136N4PX5S


    Following updated files for 9.7 inch vertical models
    MCU file please click Here
    OS file please click Here


    Available unit :  JY- VO101N4PX5S , JY-VOS01N4PX5S



    Following updated files for 9.7 inch vertical models with DSP (motherboard comes with nut chips )
    MCU file please click Here
    OS file please click Here


    Available unit :  JY- VO101N4PX5S , JY-VOS01N4PX5S



    please noted following when you update :

    1) please update the MCU files firstly and then update the OS files .
    2) The updated files for the head unit with DSP is different with the unit has ASP .
    if update the wrong files , the head unit will have no sound .
    (you can judge by EQ interface . The previous normal EQ interface is ASP , currently internal DSP with nut chip interface is DSP )

    3)For universal head unit update you need to use the left USB on the back of the head unit (the head unit need to be opposite directly to you )
    or you can update with sd card .
    if your head unit is special unit , you need to connect the USB/CP port to update .

    4) please kindly prepare 2 USB drivers or 2 sd card (class 10)
    after finish updating the MCU files , the head unit will reboot automatically . after reboot and enter into the home interface please disconnect the
    USB driver .MCU updated time will be a little short .
    and then connect the USB which with OS files , the OS update will need a little more time .
    during the update , please do not disconnect the USB driver . after finishing the update and show the "update successfully "tips then you disconnect
    the USB driver .




    Following is the updated files (2018-7-16 ) for Octa Core Processor Android 8.0 Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM /64GB

    (Please noted : if you are not clear whether you can udpate following files , please contact us  europe@joyingauto.com .  otherwise the head unit will be bad if you udpate the wrong files )


    Android 8.0.0 update to Android 8.1.0


    Available unit :
    Universal unit : JY-UO135N2PXC,JY-UO135N2PX5R,JY-UO135N2PX5,JY-UOS04N2PX5, JY-UOS01N4PX5, JY-UOS03N4PX5,JY-UOS02N4PX5
    JY-UOS03N4PX5S, JY-UO135N4PX5,JY-UO138N4PX5,JY-UO134N4PX5,JY-UO135N4PX5S,JY-UO138N4PX5S


    Toyota unit : JY-TO138N4PX5, JY-TO139N4PX5,JY-TO138N4PX5S



    Here is the firmware updated link for 1024*600, please click Here
    Here is the firmware updated link for 800*480, please click Here






    Following is the updated files (2018-4-20 ) for Octa Core Processor Android Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM
    Android 8.0 update to Android 8.0


    Here is the firmware updated link for 1024*600, please click Here
    Here is the firmware updated link for 800*480, please click Here


    This update has the below features:
    1. Add Z-Link app to run the Android Auto and iPhone Carplay
    2. Optimize the System and apps

    Kindly Warning:


    1). Please download it from your windows computer and unzip it
    2). Copy the unzipped files into an empty USB FAT32
    3). Insert the USB into your car radio left side USB connector (the side without Wifi and GPS cable), then the unit will update automatically (if the head unit cannot detect the firmware to update, you can enter the car radio Settings - System and click the System Update button)
    4). When updating, pls do not operate it and just wait it until the screen remind you to move the USB
    5). After you remove the USB drive, the unit will restart automatically. After it reboot you need calibrate the touch screen.

    After update succeed then you will find the Z-LINK app in the system menu, for the first time to run Z-Link app, you need connect the unit with internet.
    Then when you enter the Z-Link app, it will remind you to fill in the Activation Code. Pls contact us europe@joyingauto.com to get the Activation Code.
    here is the video on how to update the system , please check :

    If your have any abnormal situation during updating (like stuck in the logo, black screen, etc), please do not worry and feel free to contact us europe@joyingauto.com






    Following is the updated files (2018-4-20 ) for Octa Core Processor Android Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM
    Android 6.0 update to Android 8.0


    Here is the firmware updated link for 1024*600, please click Here
    Here is the firmware updated link for 800*480, please click Here


    (Note: before upgrade, pls prepare a USB disk and a SD card which with the same firmware )

    1). Pls download it from your windows computer and unzip it
    2). Copy the unzipped files into High Quality empty USB disk FAT32 and empty 32GB C10 SD Card
    3). Insert the USB disk into your car radio left side USB connector(the side without Wifi and GPS cable), then the unit will update automatically
    4). When use the USB updating, the unit enter recovery page to upgrade, then it will show "Doing Actions Failed ! Pls Remove the USB Disk... "
    5). Then Remove the USB disk(pls do not turn off the unit), and insert the SD card to unit GPS Map slot directly, and click the reset button, then the unit will upgrade automatically(Pls attention, The SD card should have the same firmware with the USB disk in)
    6). When updating, pls do not operate it and just wait it until the screen remind you to move the USB
    7). After you remove the USB drive, the unit will restart automatically. After it reboot you need calibrate the touch screen.

    Details on how to update the system , please see below :


    If you have any abnormal situation during updating (like stuck in the logo, black screen, etc), please do not worry and feel free to contact us europe@joyingauto.com






    Following is the updated files (2018-1-26 ) for Octa Core Processor Android Car Radio with 2GB RAM + 16GB ROM


    Here is MCU update link, please click Here .
    Here is system update link for HD 1024*600 resolution , please click Here .
    Here is system update link for HD 800*480 resolution , please click Here .


    Here is the video on how to update the system :




    Before you update the head unit, please backup all important things:
    1) Copy maps from car stereo internal storage to SD card.
     2) Go to settings-factory settings-enter password 126-canbus setting to check canbus protocol and record it.
    3) Use a good quality SD card or USB to update it (format the SD card or USB as FAT32)

    After you finish the update, you are required to do the below things:
    1) After you update, you need to connect WiFi to activate carplay function. Only left side USB port has carplay function. if you want to use Android auto, please insatll android auto app from google play store, then connect android Phone via USB cable to left side USB port. Connect Bluetooth, and android auto function can work.
    2) If your car stereo is VW special model, front and parking sensor can work well after this update.


    Have any problems during update , please contact us europe@joyingauto.com . we will try best to help you .


    Continus Reading »
  7. JOYING Intel SOFIA Android Car Stereo Software Update

    新建网页 3

    JOYING Intel SOFIA Android Car Stereo Software Update



    Note: this update page is only workable for android car radio with Intel SOFIA 3RG CPU, please contact us to confirm update file if you are not clear about your head unit system . otherwise the head unit will be damaged .

    Following are the head unit model which workable for update .

    Universal head unit :

    JY-UM135N, JY-UM135N2 , JY-UM124N,JY-UM124N2, JY-UM138N, JY-UM138N2,JY-UM134N,JY-UM134N2 , JY-UM128N,JY-UM128N2

    JY-UMS01N, JY-UMS01N2,JY-UMS02N,JY-UMS02N2, JY-UMS03N,JY-UMS03N2,JY-UMS04N

    Toyota car head unit :

    JY-TL121N2,JY-TL122N2,JY-TL123n2,JY-TL124N2, JY-TL135N2,JY-TL138N2,JY-TL139N2,

    JY-TM121N2,JY-TM122N2,JY-TM123n2,JY-TM124N2, JY-TM135N2,JY-TM138N2,JY-TM139N2

    VW car head unit :


    JY-VL130N2, JY-VL131N2,JY-VL132N2, JY-VM130N2, JY-VM131N2,JY-VM132N2

    Nissan car head unit :

    JY-NL135N2 ,JY-NL124N2, JY-NL134N2, JY-NM135N2 ,JY-NM124N2, JY-NM134N2

    Honda car head unit :

    JY-HL121N2, JY-HL124N2,JY-HL135N2 , JY-HM121N2, JY-HM124N2,JY-HM135N2

    Ford car head unit :

    JY-FL121N2, JY-FL122N2 ,JY-FL123N2 , JY-FL124N2,JY-FL125N2 , JY-FM121N2, JY-FM122N2 ,JY-FM123N2 , JY-FM124N2,JY-Fm125N2

    Jeep car head unit :

    JY-JL001N2, JY-JM001N2

    Audi car head unit :

    JY-AL001N2,JY-AL003N2, JY-AM001N2,JY-AM003N2

    Opel car head unit :

    JY-OL001N2 , JY-OM001N2

    Mazada car head unit :


    JY-ML001N2 , JY-MM001N2

    Chevy car head unit :

    JY-CL001N2, JY-CM001N2

    Mercedes Benz car head unit :


    JY-MBM01N2



    Important attention for your update :


    1) you need to unzip the updated files on the Windows system firstly. and then copy them to the USB or SD card without any other folder . The USB or SD card need to be formatted as FAT32 .
    and then insert USB or SD card into the head unit USB port or SD card slot, it will be updated automatically .

    2) please do not unzip the files on the USB or SD card.

    3) it is better to use the 32GB or less than 32gB USB or SD card .




    Below updated files is (2018-1-26) version . please check :

    Updated files for HD resolution 1024*600 :

    MCU version is 9.20 or more later please click Here

    MCU version is 5.25 or more earlier please click Here

    Here is the video on how to update the system :



    Updated files for HD resolution 800*480 :

    MCU version is 9.20 or more later please click Here

    MCU version is 5.25 or more earlier please click Here .

    Here is the video on how to update the system :

    Before you update the head unit, please backup all important things:

    1) Copy maps from car stereo internal storage to SD card.

    2) Go to car settings-enter password 3368-car model to check canbus protocol and record it.

    3) Use a good quality SD card or USB to update it (format the SD card or USB as FAT32)



    After you finish the update, you are required to do the below things:

    1) Remap touch button on the front panel.

    2) Touch calibration again.

    3) Enter the Car Settings application-go to the lower right tab (the one with the screwdriver) click on it and enter 3368- go to the AMP Enable option and turn it off-Go to the EQ menu (second lower tab from right to left) of the car settings and now have the keyboard pitch option. Note: If your android car radio is with digital amplifier, please choose AMP (in).

    4) Go to radio settings, turn on two option: auto sens and RDS. If you hear background noise after searching radio station, please turn off stereo option.

    55) Pre-installed Z-link app in OEM. If you want to use carplay or android auto in Intel SOFIA car radio, you need to purchase JOYING Z-BOX. Apple carplay for iPhone: install Zlink apk, then connect USB carplay dongle by iPhone original data cable to Android car radio. Connect WiFi,and CarPlay function can work. Android auto for Android phones: install android auto app from Google play store and install Zlink apk in OEM, then connect USB carplay dongle by android phone original data cable to Android car radio. Connect Bluetooth, and android auto function can work.

    6) If your android car radio is BMW, W, Audi or Opel, you need to set canbus protocol again like the one as before update.



    NOTE:

    1) Please contact us for correct DVR app after update

    2) 2) If your car android car stereo is universal model, please do not choose canbus protocal even if have bought third-party canbus adapter.

    3) If your car stereo is special model, front and parking sensor can work well after this update.




    If you have any problems during updating , please contact europe@joyingauto.com . we will help you .







    Continus Reading »
Page
