JOYING 2GB RAM 32GB ROM Octa Core CPU Android 6.0 Car Stereo Latest Update

　

Note: this update is only workable for Android 6.0 car radio with octa core CPU with 2GB RAM+32GB ROM . Please contact us if you are not clear your head unit system .
 otherwise the head unit will be damaged .

　

Following is the updated files (2018-5-11 ) for Octa Core Processor Android Car Radio with 2GB RAM + 32GB ROM

please noted : This firmware is only available for Joying FYT Android 6.0.1 PX5 Octa Core 2GB+32GB Radio. Pls attention: This firmware is NOT fit for Android 8.0 octa core radios, Not for 8 inch VW head unit with DVD player(JY-VM130P2), also Not for screen resolution 800*480 models. This firmware is mainly for the head unit bought before March 2018.

Update Guideline:
Here is the firmware for 1024*600 resolution models . please click Here
Applicable Car Models: JY-UM135P2, JY-UM128P2, JY-UM138P2, JY-UM134P2, JY-UMS01P2, JY-UMS02P2, JY-UMS03P2, JY-VM131P2, JY-TM138P2, JY-NM135P2, JY-NM138P2, JY-NM134P2, JY-HM135P2, JY-HYM135P2

Here is the firmware for 1280*480 resolution models. please click Here
Applicable Car Models: JY-HCS01P2(8.8 inch), JY-HCS02P2(10.25 inch)

Following is the video on how to update :

1). Pls download the firmware from your windows system computer and unzip it.
2). Copy the unzipped files into an empty USB FAT32 or empty C10 32GB SD card.
3). Insert the USB into car radio USB port or SD card into unit GPS map slot, then the unit will update automatically.
4). During the update, please do not operate it and just wait it until the screen remind you to move SD card or USB.
5). The item will reboot automatically.

After you update the head unit, please note that below things.
1) Touch calibration again.
2) Remap touch button on the left side of front panel if your car stereo is full touch screen model.
3) Set canbus protocol again like the one as before update if your android car radio is BMW, W, Audi or Opel.
4) If your android car radio is without digital amplifier, please choose No amp; If your android car radio is with digital amplifier, please choose AMP (in).

News for this update:
1). Optimized the Bluetooth (Bluetooth connecting and bluetooth music sound issue)
2). Optimized the OBD
3). Optimized the music sound issue via Apple CarPlay function
4). Optimized the unit screen display color saturability
5). Optimized the system, make the operation smoother

Following is the updated files (2018-1-26 ) for Octa Core Processor Android Car Radio with 2GB RAM + 32GB ROM

Here is system update link for HD 1024*600 resolution , please click Here .

Here is the video on how to update the system :

Before you update the head unit, please backup all important things:
1) Copy maps from car stereo internal storage to SD card.
2) Go to settings-factory- enter password 3368- car model to check canbus protocol and record it.
3) Use a good quality SD card or USB to update it (format the SD card or USB as FAT32)

After you finish the update, you are required to do the below things:
1) Remap touch button on the front panel.
2) Touch calibration.
3) Enter the Car Settings application- go to the lower right tab (the one with the screwdriver) click on it and enter 3368- go to the AMP Enable option and turn it off-Go to the EQ menu (second lower tab from right to left) of the car settings and now have the keyboard pitch option. Note: If your android car radio is with digital amplifier, please choose AMP (in).
4) Go to radio settings, turn on two option: auto sens and RDS. If you hear background noise after searching radio station, please turn off stereo option.
5) If your android car radio is BMW, VW, Audi or Opel, you need to set canbus protocol again like the one as before update.

Note:
1) Fix OBD connection problem, the code of paring OBD is 1234.
2) After you update, you need to connect WiFi to activate carplay function. Only left side USB port has carplay function. if you want to use Android auto, please insatll android auto app from google play store, then connect android Phone via USB cable to left side USB port. Connect Bluetooth, and android auto function can work.
3) Optimize widgets usage.
4) Fix popping problem when you exit single app use.
5)If your car stereo is VW special model, front and parking sensor can work well after this update.

Have any problems during update , please contact us europe@joyingauto.com. we will try best to help you .

　

JOYING Octa Core Processor Android 8.0 Car Radio Latest Update with 2GB /4GBRAM + 16GB ROM /32GB

　

Note: this update is only workable for Android car radio with octa core CPU with 2GB RAM+16GB ROM . Please contact us if you are not clear your head unit system .
 otherwise the head unit will be damaged .

Following is the updated files for Octa Core Processor Android 8.0 Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM /64GB
please noted : it can solve the android auto function supported by android 8.0 phone .
Android 8.0 update to Android 8.1 or Android 8.1 update to Android 8.1

Before update , you need to clarify your head unit with or without DSP (motherboard comes with nut chips )
following will be shown on pictures and help you how to distinguish. (if you still not clear , please contact us europe@joyingauto.com )

Following updated files for resolution 1024*600 models ,
MCU file please click Here
OS file please click Here

Available unit :
JY-UO135N2PXC,JY-UO135N2PX5R,JY-UO135N2PX5,JY-UOS04N2PX5, JY-UOS01N4PX5, JY-UOS03N4PX5,JY-UOS02N4PX5
JY-UOS03N4PX5S, JY-UO135N4PX5,JY-UO138N4PX5,JY-UO134N4PX5,JY-UO135N4PX5S,JY-UO138N4PX5S
JY-KO002N4PX5S,JY-KO003N4PX5S,JY-HO122N4PX5S,JY-FO127N4PX5S,JY-FO128N4PX5S,JY-TO151N4PX5S,JY-TO152N4PX5S,JY-TO153N4PX5S,
JY-TO154N4PX5S,JY-TO155N4PX5S,JY-TO156N4PX5S,JY-TO157N4PX5S,JY-TO158N4PX5S,JY-TO159N4PX5S, JY-HO140N4PX5S,JY-HO141N4PX5S,JY-HO142N4PX5S
JY-HO143N4PX5S,JY-VO134N4PX5S,JY-HO001N4PX5S,JY-HO002N4PX5S,JY-HO003N4PX5S,JY-NO001N4PX5S,JY-PO148N4PX5S,JY-PO138N4PX5S

Following updated files for resolution 1024*600 models with DSP (motherboard comes with nut chips )
MCU file please click Here
OS file please click Here

Available unit :
JY-UO135N2PXC,JY-UO135N2PX5R,JY-UO135N2PX5,, JY-UOS03N4PX5,JY-UOS02N4PX5
JY-UOS03N4PX5S, JY-UO135N4PX5,JY-UO138N4PX5,JY-UO134N4PX5,JY-UO135N4PX5S,JY-UO138N4PX5S
JY-KO002N4PX5S,JY-KO003N4PX5S,JY-HO122N4PX5S,JY-FO127N4PX5S,JY-FO128N4PX5S,JY-TO151N4PX5S,JY-TO152N4PX5S,JY-TO153N4PX5S,
JY-TO154N4PX5S,JY-TO155N4PX5S,JY-TO156N4PX5S,JY-TO157N4PX5S,JY-TO158N4PX5S,JY-TO159N4PX5S, JY-HO140N4PX5S,JY-HO141N4PX5S,JY-HO142N4PX5S
JY-HO143N4PX5S,JY-VO134N4PX5S,JY-HO001N4PX5S,JY-HO002N4PX5S,JY-HO003N4PX5S,JY-NO001N4PX5S,JY-PO148N4PX5S,JY-PO138N4PX5S

Following updated files for resolution 800*480 models
MCU file please click Here
OS file please click Here

Available unit : JY-JO001N4PX5S

Following updated files for resolution 800*480 models with DSP (motherboard comes with nut chips )
MCU file please click Here
OS file please click Here

Available unit : JY-JO001N4PX5S

Following updated files for 9.7 inch horizontal models
MCU file please click Here
OS file please click Here

Available unit :  JY-VOS06N4PX5S,JY-UO136N4PX5S

Following updated files for 9.7 inch horizontal models with DSP (motherboard comes with nut chips )
MCU file please click Here
OS file please click Here

Available unit :  JY-VOS06N4PX5S,JY-UO136N4PX5S

Following updated files for 9.7 inch vertical models
MCU file please click Here
OS file please click Here

Available unit :  JY- VO101N4PX5S , JY-VOS01N4PX5S

Following updated files for 9.7 inch vertical models with DSP (motherboard comes with nut chips )
MCU file please click Here
OS file please click Here

Available unit :  JY- VO101N4PX5S , JY-VOS01N4PX5S

please noted following when you update :
1) please update the MCU files firstly and then update the OS files .
2) The updated files for the head unit with DSP is different with the unit has ASP .
if update the wrong files , the head unit will have no sound .
(you can judge by EQ interface . The previous normal EQ interface is ASP , currently internal DSP with nut chip interface is DSP )

3)For universal head unit update you need to use the left USB on the back of the head unit (the head unit need to be opposite directly to you )
or you can update with sd card .
if your head unit is special unit , you need to connect the USB/CP port to update .

4) please kindly prepare 2 USB drivers or 2 sd card (class 10)
after finish updating the MCU files , the head unit will reboot automatically . after reboot and enter into the home interface please disconnect the
USB driver .MCU updated time will be a little short .
and then connect the USB which with OS files , the OS update will need a little more time .
during the update , please do not disconnect the USB driver . after finishing the update and show the "update successfully "tips then you disconnect
the USB driver .

　

Following is the updated files (2018-7-16 ) for Octa Core Processor Android 8.0 Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM /64GB

(Please noted : if you are not clear whether you can udpate following files , please contact us  europe@joyingauto.com .  otherwise the head unit will be bad if you udpate the wrong files )

Android 8.0.0 update to Android 8.1.0

Available unit :
Universal unit : JY-UO135N2PXC,JY-UO135N2PX5R,JY-UO135N2PX5,JY-UOS04N2PX5, JY-UOS01N4PX5, JY-UOS03N4PX5,JY-UOS02N4PX5
JY-UOS03N4PX5S, JY-UO135N4PX5,JY-UO138N4PX5,JY-UO134N4PX5,JY-UO135N4PX5S,JY-UO138N4PX5S

Toyota unit : JY-TO138N4PX5, JY-TO139N4PX5,JY-TO138N4PX5S

Here is the firmware updated link for 1024*600, please click Here
Here is the firmware updated link for 800*480, please click Here

Following is the updated files (2018-4-20 ) for Octa Core Processor Android Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM
Android 8.0 update to Android 8.0

Here is the firmware updated link for 1024*600, please click Here
Here is the firmware updated link for 800*480, please click Here

This update has the below features:
1. Add Z-Link app to run the Android Auto and iPhone Carplay
2. Optimize the System and apps

Kindly Warning:

1). Please download it from your windows computer and unzip it
2). Copy the unzipped files into an empty USB FAT32
3). Insert the USB into your car radio left side USB connector (the side without Wifi and GPS cable), then the unit will update automatically (if the head unit cannot detect the firmware to update, you can enter the car radio Settings - System and click the System Update button)
4). When updating, pls do not operate it and just wait it until the screen remind you to move the USB
5). After you remove the USB drive, the unit will restart automatically. After it reboot you need calibrate the touch screen.

After update succeed then you will find the Z-LINK app in the system menu, for the first time to run Z-Link app, you need connect the unit with internet.
Then when you enter the Z-Link app, it will remind you to fill in the Activation Code. Pls contact us europe@joyingauto.com to get the Activation Code.
here is the video on how to update the system , please check :

If your have any abnormal situation during updating (like stuck in the logo, black screen, etc), please do not worry and feel free to contact us europe@joyingauto.com

Following is the updated files (2018-4-20 ) for Octa Core Processor Android Car Radio with 2GB RAM + 16GB ROM/4GB RAM+32GB ROM
Android 6.0 update to Android 8.0

Here is the firmware updated link for 1024*600, please click Here
Here is the firmware updated link for 800*480, please click Here

(Note: before upgrade, pls prepare a USB disk and a SD card which with the same firmware )

1). Pls download it from your windows computer and unzip it
2). Copy the unzipped files into High Quality empty USB disk FAT32 and empty 32GB C10 SD Card
3). Insert the USB disk into your car radio left side USB connector(the side without Wifi and GPS cable), then the unit will update automatically
4). When use the USB updating, the unit enter recovery page to upgrade, then it will show "Doing Actions Failed ! Pls Remove the USB Disk... "
5). Then Remove the USB disk(pls do not turn off the unit), and insert the SD card to unit GPS Map slot directly, and click the reset button, then the unit will upgrade automatically(Pls attention, The SD card should have the same firmware with the USB disk in)
6). When updating, pls do not operate it and just wait it until the screen remind you to move the USB
7). After you remove the USB drive, the unit will restart automatically. After it reboot you need calibrate the touch screen.

Details on how to update the system , please see below :


If you have any abnormal situation during updating (like stuck in the logo, black screen, etc), please do not worry and feel free to contact us europe@joyingauto.com

Following is the updated files (2018-1-26 ) for Octa Core Processor Android Car Radio with 2GB RAM + 16GB ROM

Here is MCU update link, please click Here .
Here is system update link for HD 1024*600 resolution , please click Here .
Here is system update link for HD 800*480 resolution , please click Here .

Here is the video on how to update the system :

Before you update the head unit, please backup all important things:
1) Copy maps from car stereo internal storage to SD card.
 2) Go to settings-factory settings-enter password 126-canbus setting to check canbus protocol and record it.
3) Use a good quality SD card or USB to update it (format the SD card or USB as FAT32)

After you finish the update, you are required to do the below things:
1) After you update, you need to connect WiFi to activate carplay function. Only left side USB port has carplay function. if you want to use Android auto, please insatll android auto app from google play store, then connect android Phone via USB cable to left side USB port. Connect Bluetooth, and android auto function can work.
2) If your car stereo is VW special model, front and parking sensor can work well after this update.


Have any problems during update , please contact us europe@joyingauto.com . we will try best to help you .
　

JOYING Intel SOFIA Android Car Stereo Software Update

Note: this update page is only workable for android car radio with Intel SOFIA 3RG CPU, please contact us to confirm update file if you are not clear about your head unit system . otherwise the head unit will be damaged .

Following are the head unit model which workable for update .

Universal head unit :

JY-UM135N, JY-UM135N2 , JY-UM124N,JY-UM124N2, JY-UM138N, JY-UM138N2,JY-UM134N,JY-UM134N2 , JY-UM128N,JY-UM128N2

JY-UMS01N, JY-UMS01N2,JY-UMS02N,JY-UMS02N2, JY-UMS03N,JY-UMS03N2,JY-UMS04N

Toyota car head unit :

JY-TL121N2,JY-TL122N2,JY-TL123n2,JY-TL124N2, JY-TL135N2,JY-TL138N2,JY-TL139N2,

JY-TM121N2,JY-TM122N2,JY-TM123n2,JY-TM124N2, JY-TM135N2,JY-TM138N2,JY-TM139N2

VW car head unit :

JY-VL130N2, JY-VL131N2,JY-VL132N2, JY-VM130N2, JY-VM131N2,JY-VM132N2

Nissan car head unit :

JY-NL135N2 ,JY-NL124N2, JY-NL134N2, JY-NM135N2 ,JY-NM124N2, JY-NM134N2

Honda car head unit :

JY-HL121N2, JY-HL124N2,JY-HL135N2 , JY-HM121N2, JY-HM124N2,JY-HM135N2

Ford car head unit :

JY-FL121N2, JY-FL122N2 ,JY-FL123N2 , JY-FL124N2,JY-FL125N2 , JY-FM121N2, JY-FM122N2 ,JY-FM123N2 , JY-FM124N2,JY-Fm125N2

Jeep car head unit :

JY-JL001N2, JY-JM001N2

Audi car head unit :

JY-AL001N2,JY-AL003N2, JY-AM001N2,JY-AM003N2

Opel car head unit :

JY-OL001N2 , JY-OM001N2

Mazada car head unit :

JY-ML001N2 , JY-MM001N2

Chevy car head unit :

JY-CL001N2, JY-CM001N2

Mercedes Benz car head unit :

JY-MBM01N2

　

Important attention for your update :

1) you need to unzip the updated files on the Windows system firstly. and then copy them to the USB or SD card without any other folder . The USB or SD card need to be formatted as FAT32 .
and then insert USB or SD card into the head unit USB port or SD card slot, it will be updated automatically .

2) please do not unzip the files on the USB or SD card.

3) it is better to use the 32GB or less than 32gB USB or SD card .

　


Below updated files is (2018-1-26) version . please check :

Updated files for HD resolution 1024*600 :

MCU version is 9.20 or more later please click Here

MCU version is 5.25 or more earlier please click Here

Here is the video on how to update the system :

Updated files for HD resolution 800*480 :

MCU version is 9.20 or more later please click Here

MCU version is 5.25 or more earlier please click Here .

Here is the video on how to update the system :

Before you update the head unit, please backup all important things:

1) Copy maps from car stereo internal storage to SD card.

2) Go to car settings-enter password 3368-car model to check canbus protocol and record it.

3) Use a good quality SD card or USB to update it (format the SD card or USB as FAT32)

　

After you finish the update, you are required to do the below things:

1) Remap touch button on the front panel.

2) Touch calibration again.

3) Enter the Car Settings application-go to the lower right tab (the one with the screwdriver) click on it and enter 3368- go to the AMP Enable option and turn it off-Go to the EQ menu (second lower tab from right to left) of the car settings and now have the keyboard pitch option. Note: If your android car radio is with digital amplifier, please choose AMP (in).

4) Go to radio settings, turn on two option: auto sens and RDS. If you hear background noise after searching radio station, please turn off stereo option.

55) Pre-installed Z-link app in OEM. If you want to use carplay or android auto in Intel SOFIA car radio, you need to purchase JOYING Z-BOX. Apple carplay for iPhone: install Zlink apk, then connect USB carplay dongle by iPhone original data cable to Android car radio. Connect WiFi,and CarPlay function can work. Android auto for Android phones: install android auto app from Google play store and install Zlink apk in OEM, then connect USB carplay dongle by android phone original data cable to Android car radio. Connect Bluetooth, and android auto function can work.

6) If your android car radio is BMW, W, Audi or Opel, you need to set canbus protocol again like the one as before update.

　

NOTE:

1) Please contact us for correct DVR app after update

2) 2) If your car android car stereo is universal model, please do not choose canbus protocal even if have bought third-party canbus adapter.

3) If your car stereo is special model, front and parking sensor can work well after this update.

　


If you have any problems during updating , please contact europe@joyingauto.com . we will help you .
